| Part Number | 1840538-3 6610128-1 1840538-4 1840538-2 |
| Application-LAN | ETHERNET(NoN POE) |
| AutomDX | YES |
| Bst Circuit | YES |
| Configuration RX | T,C |
| Configuration TX | T,C |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Cores Per Port | 6 |
| Diodes | NO DIODES |
| LED Option | GREEN/GREEN |
| Latch | UP |
| Number of Ports | 1x2 |
| PCB | FR4 |
| PCB Mount Angle | SIDE ENTRY |
| PCB Retaining Post | T POST |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Search | YES |
| Shield EMI Tabs | WITH |
| Shielding | Shielded |
| Speed | 10/100 Base-T |
| Temperature | 0°C ~ 70°C |
| Turns Ratio RX | 1CT:1 |
| Turns Ratio TX | 1CT:1 |
1. What are the key application areas for this RJ-45 connector?
This connector is specifically designed for standard Ethernet (Non-PoE) applications operating at 10/100 Base-T speeds.
2. Does this connector support AutoMDIX?
Yes, it features integrated AutoMDIX (AutomDX) configuration, allowing for automatic detection and adjustment of TX/RX cabling.
3. What is the operating temperature range for these parts?
These connectors are designed to operate reliably within a standard temperature range of 0°C to 70°C.
4. What type of plating and mounting configurations are available?
The contact mating area is plated with gold options (6u", 15u", or 30u"). For installation, it features side entry PCB mounting with T-post retaining posts and THT solder pins.
5. Is this product RoHS compliant?
Yes, the connector is RoHS compliant, adhering to RoHS-5 specifications with lead in solder exemption.
6. What shielding and EMI properties does this RJ-45 possess?
It features a fully shielded design equipped with EMI tabs to provide enhanced electromagnetic interference protection and maintain signal integrity.
