Send Inquiry

Product Description

Product Description
  • RJ45 Connector with integrated transformer / common mode choke
  • Power over Ethernet up to 50 Watt and speeds up to 10 Gbit/s
  • Available in SMT, THT and THT with USB
  • Compliant with standards: IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at and upcoming IEE 802.3bt
  • HPLE products: Improved Common Mode Rejection due to additional NiZn cores
RJ45 Connector
Specification
Item Value
Model Number Integrated Connector Modules
Part Status Active
Connector Type RJ45
Applications-Lan Ethernet(PoE/Non_PoE)
Speed 10/100/1000/2.5G/5G/10G Base-T, AutoMDIX
Mounting Type Through Hole
Orientation 90° Angle (Right)
Termination Solder
Contact Finish Thickness 6.00µin (0.152µm)
LED Color Yellow/Green, Green/Yellow, Green&Yellow/Green&Yellow
Number of Cores per Jack 4/6/8/12
Shielding Shielded, Emi Finger
Number of Ports 1x2 1x4 1x6 1x8 Port
Features Board Guide
Tab Direction Down/Up
Contact Finish Gold
Configuration RX/TX T, C
Turns Ratio RX/TX 1CT:1CT
Operating Temperature 0°C ~ 70°C / -40°C ~ +85°C
Packing & Delivery
  • Package: Tray
  • Carton Size: 37 * 30 * 30 cm
  • G.W./Carton: 9 kg
  • Qty/Carton: 600 pcs
  • SPQ: 30 pcs
  • N.W./Pcs: 0.015 kg
Packaging Detail
Overview
Product View 1 Product View 2 Product View 3 Product View 4 Product View 5 Product View 6 Product View 7
FAQ
How can we guarantee quality?
We guarantee quality by always providing a pre-production sample before starting mass production, and executing a final inspection process before shipment.
What can you buy from us?
You can buy RJ45 Magnetic connectors, LAN transformers, RJ11 Connectors, RJ45 Connectors, and SFP modules.
What are the accepted delivery terms?
We accept various delivery terms, including: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, and DES.
What payment currencies and types are accepted?
Accepted Payment Currencies: USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, CHF.
Accepted Payment Types: T/T, L/C, D/P, D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, and Escrow.
What operating temperature range do these connectors support?
These Integrated Connector Modules support standard operating temperatures of 0°C ~ 70°C, and industrial-grade temperatures of -40°C ~ +85°C.
What standard speeds are supported?
The RJ45 integrated connectors support speed ranges of 10/100/1000/2.5G/5G/10G Base-T with AutoMDIX capabilities.
