| Part Number | TIC-L003-11 |
| AutomDX | YES |
| Bst Circuit | YES |
| Configuration RX | T,C |
| Configuration TX | T,C |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Cores Per Port | 4 |
| Diodes | NO DIODES |
| LED Option | WithOUT LEDS |
| Latch | DOWN |
| Number of Ports | 1X1 |
| PCB | FR4 |
| PCB Mount Angle | SIDE ENTRY |
| PCB Retaining Post | T POST |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 With LEAD IN SOLDER EXEMPTION |
| Search | YES |
| Shield EMI Tabs | With OR WithOUT |
| Speed | 10/100 BASE-T |
| Temperature | 0 TO 70°C/-40 TO 85°C |
| Turns Ratio RX | 1CT:1 |
| Turns Ratio TX | 1CT:1 |
World's Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers
What is the specific part number of this RJ45 connector?
The specific part number for this female RJ45 internet modular plug is TIC-L003-11.
What speed levels does this modular plug support?
The TIC-L003-11 supports 10/100 BASE-T network transmission speeds.
Does this female RJ45 connector include integrated LEDs?
No, this particular model is designed without LEDs and also features no diodes.
What are the PCB mounting angle and latch orientation specifications?
It has a side entry (right angle) PCB mounting angle and a downward latch orientation (Latch Down).
What is the operating temperature range for the TIC-L003-11?
The operating temperature range is certified from 0 to 70°C for standard applications, and from -40 to 85°C for extended environments.
Is the TIC-L003-11 modular plug RoHS compliant?
Yes, it is certified RoHS-5 compliant (with lead in solder exemption) and aligns with active environmental standards.
