| Item | 40G QSFP+ Module |
| Part Status | Active |
| Form Factor | QSFP+ |
| Max Data Rate | 40G |
| Wavelength | 1310nm |
| Max Cable Distance | 80KM |
| Connector | Duplex LC |
| Media | SMF |
| Optical Component | EML/PIN |
| TX Power | 1~6dBm |
| Receiver Sensitivity | <-25dBm |
| Receiver Overload | -8dBm |
| Power Consumption | ≤4.5W |
| DDM/DOM | DDM Supported |
| Commercial Temp Range | 0 to 70°C (32 to 158°F) |
| Protocols | QSFP+ MSA, IEEE 802.3ba Compliant |
| Warranty | 5 Years |
| Sample | Available |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module.
We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
We provide end-to-end DWDM devices with almost all optical elements—from active modules to optical passive components, including optical amplifiers (EDFA & RFA), Mux & Demux, OPM, ROADM, MCS, OLP, and OTDR.
To meet the demand of massive data transmission in data centers, we have developed a series of high-speed optical modules with rates ranging from 10G to 800G, providing high-quality optical interconnection solutions.
We provide high reliability and high-performance products using mature, efficient lasers and mainstream chip solutions. The catalog covers Dark Fiber, WDM, Radio over Fiber, High Speed, Mid-haul, and Back-haul options for 4G/5G systems.
Aimed at global communication network constructors, we provide total FTTx optical fiber access solutions covering all-optical or combined optical-copper access architectures.
To ensure the normal operation of optical lines, we offer optical cable O&M solutions that integrate an optical line protection system (OLP) and an optical line monitoring system (OLM).
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, RoHS, REACH, CE, and UL. Our facilities host advanced manufacturing systems and inspection instruments imported from abroad.
Established in 1997, our production processes employ around 2,000 workers. With a monthly capacity of up to 3,000K units, we are capable of delivering orders within a tight time frame.
Additionally, we offer a comprehensive portfolio of optical transceivers for data centers, access lines, wireless base stations, and metropolitan networks. Our goal is to leverage advanced optoelectronics technology to research, develop, and distribute optical infrastructure solutions globally.
We are a specialized manufacturer of magnetic telecom and networking components, including RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
Yes, we can offer free samples for quality evaluation, though shipping costs are to be covered by the client.
In-stock items are ready for shipment immediately. Mass production orders generally take between 15 to 30 days.
We offer a one-year warranty period along with 24-hour online technical support.
Yes, we support both OEM and ODM requirements. Please send us your specifications to start a detailed discussion.
We bring over 19 years of manufacturing experience, backed by stable relationships with leading global enterprise partners.
