2.5GBASE-SX Multimode 850nm 2.5G SFP Module 300m Duplex LC MMF Optical Transceiver

Product Description

2.5GBASE-SX Multimode 850nm 2.5G SFP Module 300m Duplex LC MMF Optical Transceiver
SFP Modules Overview
Products Description
Item 2.5G SFP
Part Status Active
Form Factor SFP
Max Data Rate 2.5Gbps
Wavelength 850nm
Max Cable Distance 300m
Media MMF
Connector Duplex LC
Optical Component VCSEL/PIN
TX Power -10~-3dBm
Receiver Sensitivity <-18dBm
Receiver Overload -3dBm
Power Consumption 1W
Extinction Ratio >8.2dB
DDM/DOM Supported
Commercial Temperature Range -10 to 70°C (-37 to 158°F)
Protocols SFP MSA(INF-8074i), GR-253-CORE, ITU-T G.957, FC-PI v2.0, SFF-8472 v9.5
Warranty 5 Years
Sample Available
Product Specification Diagram
Product Detail Illustration
Detail Image 1
Detail Image 2
Detail Image 3
Detail Image 4
Detail Image 5
Product Component View
Related Products SFP Cage
Related SFP Cage Option 1
Related SFP Cage Option 2
Why Choose Us
Advantage Panel 1
Advantage Panel 2
Advantage Panel 3
Advantage Panel 4
Advantage Panel 5
Company Profile
We are a specialized manufacturer of magnetic telecom and networking components, certificated by ISO9001:2000, ROSH, REACH, CE and UL, owning advanced manufacturing facilities and test equipments imported from abroad. Established in 1997, we have around 2000 staff at present. With the abundant productive capacity of 3000K per month, we are able to deliver the goods within a short time. Moreover, we can provide professional complete solutions for magnetic components and strong technical support as well.

Main Products: 10/100/1000M LAN pulse transformer and filter, RJ45 connector with 10/100/1000M magnetic, T1/E1, T3/DS3/E3/STS-1 interface line transformer, ISDN, HDSL, ADSL and VDSL interface line transformer and splitter. Our products are widely used in networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem. We have exported our products to more than 30 countries and regions in the world, covering Germany, France, England, USA, Singapore, Korea, Canada, and Japan.

Our engineering staff is dedicated to identifying, developing, and manufacturing the optimal solution for our customers' unique requirements. We trust that our strength in the field and our commitment to high quality will satisfy your operational needs.
Production Workshop
Quality Inspection Center
Frequently Asked Questions
Q1: Are you a factory or a trading company?
We are a specialized manufacturer of magnetic telecom and networking components, including RJ45 connectors, LAN transformers, RJ11 connectors, SFP modules, and related products.
Q2: Can I get a sample before mass production?
Yes, we can offer you free samples to test quality, though the shipping fee will need to be covered by the customer.
Q3: What is your typical delivery time?
Products in stock are ready to ship immediately. For mass production orders, the delivery timeframe is generally 15-30 days.
Q4: What after-sales service do you provide?
We offer a one-year guarantee period along with 24-hour online technical support to assist you with any inquiries.
Q5: Do you accept OEM or ODM orders?
Yes, we welcome OEM and ODM requirements. Please contact us directly so we can discuss the technical specifications in detail.
Q6: What are your key advantages?
We possess over 19 years of dedicated manufacturing experience, acting as a trusted components partner for top-tier international tech firms.
