| Item | Specifications |
|---|---|
| Item | 10G Optical Modules |
| Replaceable Part | Cisco, HW, Arista, Juniper, Brocade, Intel, etc |
| Part Status | Active |
| Form Factor | SFP+ |
| Max Data Rate | 10Gbps |
| Cable Type | Copper |
| Max Cable Distance | 30m@Cat6a/Cat7 or Better |
| Connector | RJ-45 |
| EMC | Supported |
| Power Consumption | ≤2.9W |
| MTBF | 5,000,000 Hours |
| DDM | Supported |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Protocols | IEEE 802.3an, IEEE 802.3az, SFP+ MSA, SFF-8431 |
| Warranty | 5 Years |
| Sample | Available |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module.
We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
| Part Number | Data Rate | Connector | Media | Distance |
|---|---|---|---|---|
| LP-FE-TCB | 10/100Mbps | RJ45 | Cat 5/Cat 6/Cat 6a | 100m |
| LP-RJ4501-TC | 100Mbps | RJ45 | Cat 5/Cat 6/Cat 6a | 100m |
| LP-SFP-TMRC | 10/100/1000Mbps | RJ45 | Cat 6/Cat 6a | 100m |
| LP-SFP-TM8C | 10/100/1000Mbps | RJ45 | Cat 6/Cat 6a | 100m |
| LP-SFP-MS8C | 1000Mbps | RJ45 | Cat 6/Cat 6a | 100m |
| LP-SFP-MSRC | 1000Mbps | RJ45 | Cat 6/Cat 6a | 100m |
| LP-RJ452G-TC | 2.5Gbps | RJ45 | Cat5e | 100m |
| LP-RJ45TG-3YC | 10Gbps | RJ45 | Cat6a/Cat7 or Better | 30m |
| LP-RJ45TG-8YC | 10Gbps | RJ45 | Cat6a/Cat7 or Better | 80m |
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, RoHS, REACH, CE and UL, and equipped with advanced manufacturing facilities and testing instruments imported from abroad.
Established in 1997, our production facilities house around 2,000 staff members. With an abundant monthly production capacity of 3,000K units, we are capable of delivering products within short lead times.
Moreover, we provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks. The range also offers high-speed optical interconnection solutions for cloud computing and ultra-broadband networks. Using the latest optoelectronics technologies, we develop, manufacture, and distribute products globally.
